Acme-Gridley  RA-4 & RA-6 Automatic Bar Machine

  Parts Manual

For models: RA-4 size 3 1/2" , RA-6 sizes 2" , 2 1/4" , & 2 5/8"

Description: This manual covers the parts breakdown, part numbers, & assembly drawings of the Acme Gridley Automatic Bar Machine.  To inspect the quality, please click on the gallery images above to enlarge.

Includes sections on:

• Parts List
• Assembly Drawings


Number of pages: Approx 20
Condition of original: Very Good
Publication No.:  N/A
Publication date: April 1943
Added Notes:

About This Manual:  This is a high quality reproduction manual which has been scanned with a high resolution scanner.  Each page is then digitally edited in Photoshop to remove grease marks, fingerprints, writing, and other imperfections that the original manual may have had.  It is then printed on 24 lb heavy paper and 65 lb cardstock for the covers with a 600 DPI LaserJet printer.  The result is a clean and durable manual which many times is better than the original and should last many years in your shop.

Questions?
Email: eugene@fabersurplus.com
Phone: 316-210-4079 after 11:00 am Central Time

Ships USPS First Class Free or
Upgrade to Priority Mail for faster delivery.

Reprinted from original manual using high quality 24lb
paper and comb binding.

Covers are printed from 65lb cardstock for extra durability.
