Bridgeport Series I Step Pulley 1hp Milling Machine
Operation and Parts Manual

For Models: Series I with Step Pulley. s/n's:(approx) BR-31618 up

Description: This manual covers the Bridgeport Milling Machine Series I which uses the step pulley instead of a variable speed for speed changes.  It covers machines built starting in 1956.  It covers Installation, Lubrication, Alignment, Adjustments, General Operation, Power Feed Attachment, Operation of the 1hp J-Head, Parts lists and Sectional Drawings of the 1 hp J-Head, 1/2hp R-Head, 1/4hp C-Head,1/2hp M-Head, Power Feed Attachment, Shaping Attachment, Cherrying Attachment, Quill Unit, and this manual also includes the Operation and Parts List for the optional Optical Measuring System that other manuals don't include.  The manual has 44 pages.  To view the Table of Contents and sample pages, and to inspect the quality of the manual, please click on the above gallery images.


Includes sections on

• Installation
• Operation

• Lubrication
• Head Alignment
• Gib Adjustments
• Power Feed Attachment
• Installing Power Feed Attachment
• Installation & Use of the Measuring Attachment
• Placing and Adjusting Beltss
• Operating Instruction of "J" Attachment
• Speeds and Feeds Chart
• Optical Measuring System
• Parts List & Drawings for "J" Attachment
• Parts  List for Quill Unit
• Parts List & Drawing for Back Gear Transmission
• V Belt Unit Parts List
• Quill Pinion & Overload Clutch Assembly Parts List
• Feed Transmission Unit Parts List
• No. 4 Belt Housing
• Brake & Clutch Unit Parts List
• Parts List & Drawing on BR Turret Milling Machine
• Parts List & Drawing for Power Feed Attachment
• Parts List & Drawing for Model "M" Attachment
• Parts List & Drawing for Model "R" Attachment
• Parts List & Drawing for Model "C" Attachment
• Parts List & Drawing for Cherrying Attachment
• Parts List & Drawing for Shaper Attachment
• Parts List & Drawing for Optical Measuring System



Number of Pages: Approx. 44
Publication Date: 1960
Publication No.: N/A

Added Notes: Due to others making copies of these for resale, I have added a light watermark to select pages to discourage this practice.

About this manual: This is a high quality reproduction manual which has been scanned with a high resolution scanner.  Each page is then digitally edited in Photoshop to remove grease marks, fingerprints, writing, and other imperfections that the original manual may have had.  It is then printed on 24 lb heavy paper and 65 lb cardstock for the covers with a 600 DPI LaserJet printer.  The result is a clean and durable manual which many times is better than the original and should last many years in your shop.
