Deckel  Universal Copy Milling Machine KF2

Operators  Manual

For models: KF2

Description: This is an Operators Manual for the Deckel KF-2 Milling Machine. It has sections on: Installation, Operation, Specifications, Lubrication & Maintenance, Belt Tension & Replacement, How to Set Up Attachments, Indexing Head, The manual has 55 pages.  To inspect the quality of the manual, to view the table of contents, and to view select pages,  please click on the gallery images above to enlarge.


Includes sections on:

• Operation
• Installation
• Specifications
• Lubrication
• Maintenance
• Belt Tension & Replacement
• Variable Drive System
• Rough Milling Spindle Unit
• Finish Milling Spindle Unit
• Fine Finishing Spindle Unit
• Pantograph
• Automatic Depth Fee Mechanism
• Line-by-Line Milling Attachment
• Spindle Immobilizing Bracket
• Optical Tracing Attachment
• Enlarging and Reducing Attachment
• Determining Cutter Diameter
• Angular Spindle Unit with Angular Tracer Holder
• Pattern Forming Attachment
• Symmetrical Duplicating Attachment
• Circular Table (15")
• Indexing Head


Number of pages: Approx 55
Condition: Very Good
Publication date: N/A
Publication No.:  N/A

Added Notes: Due to others making copies of  this manual for resale, I have added a light
watermark on select pages to discourage this practice.

About This Manual:    This is a high quality reproduction manual which has been scanned with a high resolution scanner.  Each page is then digitally edited in Photoshop to remove grease marks, fingerprints, writing, and other imperfections that the original manual may have had.  It is then printed on 24 lb heavy paper and 65 lb cardstock for the covers with a 600 DPI LaserJet printer.  The result is a clean and durable manual which many times is better than the original and should last many years in your shop.
