Edison Splitdorf Model CD

  Service and Parts List Manual

For Models: CD

Description:   This is a high quality scanned reproduction of the original Edison Model CD Magnetodealer servicing manual with parts list and pictorial parts views. It covers the 2, 4, & 6 cylinder models.  It covers the magneto Dismantling, Inspection, and Reassembly in detail.  It covers point setting, magnet recharging, Magneto Testing, Impluse Starters and has a complete parts list with pictorial parts views. The manual has 22 pages. To inspect the quality of the manual, and to view select pages, click on the above gallery images to enlarge and view.

For Edison Magneto models:   CD

Includes sections on:

• Service Equipment
• Magneto Dismantling
• Magneto Inspection & Reassembly
• Point Setting
• Gear Timing
• Magnet
• Magneto Test
• Special Features and Conversions
• Impulse Starters
• Type AA Automatic Starter
• Parts List
• Pictorial Parts Views


Number of pages: Approx 22
Condition of original:  Very Good
Publication No.:  N/A
Publication date: N/A
Added Notes: Due to others making copies of this manual for resale
                       Select pages have been watermarked to discourage
                       this practice.

Questions?
Email: eugene@fabersurplus.com
Phone: 316-210-4079 after 11:00 am Central Time

Ships USPS First Class Free or
Upgrade to Priority Mail for faster delivery.

Reprinted from original manual using high quality 24lb
paper and comb binding.

Covers are printed from 65lb cardstock for extra durability.
