Fairbanks Morse Magneto Instruction & Parts Manual

   RV1, RV4, RV6, DRV2B, RV4B, & RV6B

Parts, Instruction, & Maintenance

Description:   This is a high quality scanned reproduction of the original Fairbanks-Morsedealer servicing manual Instructions and latest Service Bulletins available.  Includes coil and condenser specifications, point settings, parts breakdown list, internal timing & general service information.
  This manual has a 31 page service manual that covers in detail how to repair these magnetos. It also includes a 12 page Repair Parts List.

For F-M Magneto models:     RV1, RV4, RV6, DRV2B, RV4B, & RV6B
Includes sections on:

• Field Service & Adjustment

• Parts List
• Specifications

• Assembly Drawings
• Coil and Condenser Tests
• Timing
• Service Tools and Supplies
• Disassemble and Reassemble

Number of pages: Approx 44
Condition of original:  Very Good
Publication No.:  2807A
Publication date: Jul 1942
Added Notes:
Includes:

•  Fairbanks Morse Service Instructions #2807A
•  Fairbanks Morse Repair Parts List 9782D

•  Bulletin FM30D

Questions?
Email: eugene@fabersurplus.com
Phone: 316-210-4079 after 11:00 am Central Time

Ships USPS First Class Free or
Upgrade to Priority Mail for faster delivery.

Reprinted from original manual using high quality 24lb
paper and comb binding.

Covers are printed from 65lb cardstock for extra durability.
