Gleason Tables for Spiral Bevel Gear System
Gear Design Manual

Standardized Tooth Proportions For Generated Spiral Bevel Gears

Description: This manual covers the necessary design criteria for the spiral  bevel gear systems.  The Tables of Tooth Proportions give the Linear and Angular Dimensions for generated gears and pinions operating at right angles in either speed-decreasing or speed-increasing drives.  The tables cover pinion/gear ratios from 12/26 to 30/98.    It contains 146 pages.  To inspect the quality of the manual,  and to view select pages, please click on the gallery images above.

Includes sections on

• Gleason Spiral Bevel Gear System
• General Features
• Whole Depth
• Face Angles
• Tooth Thickness
• Spiral Angle
• Face Width
• Backlash
• Spiral Bevel Gear Dimensions Formulas
• Data For Angular Spiral Bevel Gears
• Tables of Tooth Proportions
• Data included in Tables:

1. Pressure Angle
2. Outer Cone Distance
3. Addendum
4. Dedendum
5. Pitch Angle
6. Dedendum Angle
7. Face Angle of Blank
8. Root Angle
9.  Outside Diameter
10. Pitch Apex to Crown


Number of Pages: Approx. 146
Publication Date: 1960
Publication No.: N/A

Added Notes: Due to others making copies of these for resale, I have added a light watermark to select pages to discourage this practice.

About this manual: This is a high quality reproduction manual which has been scanned with a high resolution scanner.  Each page is then digitally edited in Photoshop to remove grease marks, fingerprints, writing, and other imperfections that the original manual may have had.  It is then printed on 24 lb heavy paper and 65 lb cardstock for the covers with a 600 DPI LaserJet printer.  The result is a clean and durable manual which many times is better than the original and should last many years in your shop.
