For models: Model AHC - S/N's 1200 and up.

Description: This manual covers the Hardinge AHC Super-Precicion Automatic Chucker and Bar Machine.   It has sections on:  Installation, Operation, Hydraulic Line Bleeding, Collet Closer, Spindle Drive Unit, Programming Functions, Headstock Spindle Tooling, Turret Tooling, General Tooling, Specifications, and more. It has 33 pages.   To inspect the quality of the manual, to view the table of contents, and to view select pages,  please click on the gallery images above to enlarge.

Includes sections on:

• Automatic Operation
• Carriage Feed Rate
• Cleaning Machine
• Collet Closer, Adjustment
• Coolant Facilities
• Cross Slide Feed Rate
• Dwell Controls
• Hydraulic System
• Index Motor
• Machine Installation
• Lubrication
• Manual Operation and Machine Setup
• Programming Functions
• Programming Paths
• Specifications
• Spindle, Brake
• Optional Tooling


Number of pages: Approx 33
Publication date:N/A
Publication No.: N/A

About This Manual:    This is a high quality reproduction manual which has been scanned with a high resolution scanner.  Each page is then digitally edited in Photoshop to remove grease marks, fingerprints, writing, and other imperfections that the original manual may have had.  It is then printed on 24 lb heavy paper and 65 lb cardstock for the covers with a 600 DPI LaserJet printer.  The result is a clean and durable manual which many times is better than the original and should last many years in your shop.

Added Notes: Due to others making copies of these manuals for resale,I have lightly watermarked select pages to discourage this practice.
