Kearney Trecker Milling Machine Standard Attachments

Repair Parts  Manual

For models: 1H-2HL-2H-2E-1CH-2CHL

Description: This is a Standard Attachments Repair Parts List Manual for the Kearney & Trecker Knee Type Milling Machines It has Assembly Drawings and Parts Lists. The manual has 63 pages.  To inspect the quality of the manual, view the table of contents, and to view select pages,  please click on the gallery images above to enlarge.


Includes sections on:

• 12" Rotary Table
• Rotary Table Drive Bracket
• Heavy Duty Vertical Milling Attachment
• 16" and 20" Rotary Tables
• Right Angle Drive Bracket
• Rack Indexing Attachment
• Thread Milling Attachment
• Crane Attachment
• Light High Speed Universal Milling Attachment
• Heavy Duty Universal Milling Attachment
• Slotting Attachment
• Rack Milling Attachment

• Parts Lists

Number of pages: Approx 63
Condition: Very Good
Publication date: N/A
Publication No.:  48

Added Notes: Due to others making copies of  this manual for resale, I have added a light
watermark on select pages to discourage this practice.

About This Manual:    This is a high quality reproduction manual which has been scanned with a high resolution scanner.  Each page is then digitally edited in Photoshop to remove grease marks, fingerprints, writing, and other imperfections that the original manual may have had.  It is then printed on 24 lb heavy paper and 65 lb cardstock for the covers with a 600 DPI LaserJet printer.  The result is a clean and durable manual which many times is better than the original and should last many years in your shop.
