Logan 10" Lathe 200 Series

Instruction &  Parts List  Manual

For models: 10"  Models 200, 201, 210, & 211

Description: This is a Instruction and Parts List Manual for the Logan 200 Series Lathes. It has sections on:  Lubrication, Operation, Chart of Threads & Feeds, &  Parts Section with Exploded Parts Views. The manual has 40 pages.  To inspect the quality of the manual,  and to view select pages,  please click on the gallery images above to enlarge.


Includes sections on:

• Lubrication
• Operation
• Maintenance
• Belt Adjustments
• Chart of Threads & Feeds
• Belt Lacing
• Tool Bits
• Exploded Parts Views
• Parts List


Number of pages: Approx 40
Condition: Very Good
Publication date: N/A
Publication No.:  N/A

Added Notes: Due to others making copies of  this manual for resale, I have added a light
watermark on select pages to discourage this practice.

About This Manual:    This is a high quality reproduction manual which has been scanned with a high resolution scanner.  Each page is then digitally edited in Photoshop to remove grease marks, fingerprints, writing, and other imperfections that the original manual may have had.  It is then printed on 24 lb heavy paper and 65 lb cardstock for the covers with a 600 DPI LaserJet printer.  The result is a clean and durable manual which many times is better than the original and should last many years in your shop.
