Magneto Ignition Fundamentals
Covering Theory and Service Procedures

Theory & Service Procedure Manual

For Models: All Magnetos

Description: This manual was used as a textbook to teach Magneto Theory and Servicing Procedures. The manual starts from the basics so it is easy for anyone to understand how magnetos work.  Knowing how a magneto works can make it much easier to service a magneto even if you don't have the dealer servicing information for that magneto.  It covers Fundamentals of Electricity, Magneto Operating Principles, Magnetic and Electrical Circuits, Condensers, Coils, Magnetizing, Testing, General Servicing Information, and more.  It contains 73 pages. To view the Table of Contents, to inspect the quality of the manual,  and to view select pages, please click on the gallery images above.


Includes sections on

• Fundamentals of Electricity
• Magnetism
• Low Tension Induction Coil with Battery and Ignitor
• Magneto Operating Principles (Edge Gap Adjustment)
• Contacts
• Condensors
• Coils
• General Service Information
• Magnetizing
• Magneto Testing
• Magneto Application and Impulse Couplings


Number of Pages: Approx. 73
Publication Date: 1941
Publication No.: N/A

Added Notes: Due to others making copies of these for resale, I have added a light watermark to select pages to discourage this practice.
