Suggested Unit Course in Shaper Work
Instruction Manual
For Models: All Metalworking Shapers

Description: This is a  course in Metalworking Shaper Operation that was given in the New York schools to teach machinists shaper operation for making parts for the war effort.  It is an excellent manual that teaches beginners metalworking shaper procedures and operations.  This manual is widely considered to be one of the best textbooks on shaper work available.  It contains 333 pages.  To view the Table of Contents, to inspect the quality of the manual,  and to view select pages, please click on the gallery images above.


Includes sections on

• Description of the Crank Shaper
• Description of the Hydraulic Shaper
• Description of Work Holding Devices
• How to Oil the Shaper
• How to Adjust the Shaper
• How to Mount Work-Holding Devices
• Description of Shaper Tool Holders
• Description of Horizontal, Vertical, and Combined Cuts
• Description of Angular Cuts
• Description of Slotting, Serrating, & SImple Form Cutting
• Speeds and Feeds
• Bench or Floor Grinder
• Grinding Wheels

Number of Pages: Approx. 333
Publication Date: 1944
Publication No.: N/A

Added Notes: Due to others making copies of these for resale, I have added a light watermark to select pages to discourage this practice.

About this manual: This is a high quality reproduction manual which has been scanned with a high resolution scanner.  Each page is then digitally edited in Photoshop to remove grease marks, fingerprints, writing, and other imperfections that the original manual may have had.  It is then printed on 24 lb heavy paper and 65 lb cardstock for the covers with a 600 DPI LaserJet printer.  The result is a clean and durable manual which many times is better than the original and should last many years in your shop.

Questions?
Email: eugene@fabersurplus.com
Phone: 316-210-4079 after 11:00 am Central Time
Please leave message as I may not hear the phone

Ships USPS First Class Free or
Upgrade to Priority Mail for faster delivery.

Reprinted from original manual using high quality 24lb paper and comb binding. Covers are printed from 65lb cardstock for extra durability.
