Nebel Rahn-Larmon Lathes
Operator & Parts Manual

For Models: AA, AG, B, D, F, G, LA, LN, & N

Description: This is an operators and parts manual for the Nebel Lathes, Formerly Rahn-Larmon Lathes.  It has Installation Instructions, Operating Instructions, Lubrication and Adjustment Instructions and more.  It includes pictorial parts views.  It contains 24 pages.  While the manual is not dated, it appears to be from the 1920's or 1930's.  To inspect the quality of the manual,  and to view select pages, please click on the gallery images above.


Includes sections on

• Operation
• Installation
• Geared Headstock
• Adjustment of Friction Clutch on Driving Sheave
• Adjustment of Timken Bearings in Main Driving Sheave
• Cone Head Stock
• Feeding and Screw Cutting
• Thread Cutting Instructions
• Apron and Carriage
• Chasing Dial
• Compound Rest
• Tail Stock
• Extension and Gap Bed Lathes
• Plain Taper Attachment
• Repair Parts Pictures

• Parts List

Number of Pages: Approx. 24
Publication Date: 1920's  to 1930's
Publication No.: OM-60

Added Notes: Due to others making copies of these for resale, I have added a light watermark to select pages to discourage this practice.

About this manual: This is a high quality reproduction manual which has been scanned with a high resolution scanner.  Each page is then digitally edited in Photoshop to remove grease marks, fingerprints, writing, and other imperfections that the original manual may have had.  It is then printed on 24 lb heavy paper and 65 lb cardstock for the covers with a 600 DPI LaserJet printer.  The result is a clean and durable manual which many times is better than the original and should last many years in your shop.

Questions?
Email: eugene@fabersurplus.com
Phone: 316-210-4079 after 11:00 am Central Time
Please leave message as I may not hear the phone

Ships USPS First Class Free or
Upgrade to Priority Mail for faster delivery.

Reprinted from original manual using high quality 24lbpaper and comb binding. Covers are printed from 65lb cardstock for extra durability.
