Norton 14"-16" Type C Cylindrical & Roll Grinder
Operation & Servicing Manual

For Models:14"-16" Type C Cylindrical
             14"-16" Type C Roll
             Heavy Duty Hi-Swing Grinder

Description: This manual covers Norton 14 to 16 inch Type C Cylindrical, Roll, and Heavy Duty Hi-Swing Grinders.    It covers the Installation, Operation, Lubrication, Grinding Procedures, and Servicing.  It contains approx. 84 pages.  To view the Table of Contents, to inspect the quality of the manual,  and to view select pages, please click on the gallery images above.


Includes sections on

• Installation
• Operation
• Tables
• Headstocks
• Live Spindle Attachments
• Footstock-Type S
• Wheel Unit
• Pumps
• Feed Screw
• Lubrication
• Hand Traverse Machines
• Mechanical Traverse Machines
• Traverse Drive
• Hydraulic Machines
• Grinding Procedure & General Instruction
• Wheel Selection
• Work Support
• Setting Up Routine
• Grinding Compounds
• Work Wheel & Traverse Speeds
• Vibration


Number of Pages: Approx. 84
Publication Date: N/A
Publication No.: 1545-4

Added Notes: Due to others making copies of these for resale, I have added a light watermark to select pages to discourage this practice.

About this manual: This is a high quality reproduction manual which has been scanned with a high resolution scanner.  Each page is then digitally edited in Photoshop to remove grease marks, fingerprints, writing, and other imperfections that the original manual may have had.  It is then printed on 24 lb heavy paper and 65 lb cardstock for the covers with a 600 DPI LaserJet printer.  The result is a clean and durable manual which many times is better than the original and should last many years in your shop.

Questions?
Email: eugene@fabersurplus.com
Phone: 316-210-4079 after 11:00 am Central Time
Please leave message as I may not hear the phone

Ships USPS First Class Free or
Upgrade to Priority Mail for faster delivery.

Reprinted from original manual using high quality 24lb paper and comb binding. Covers are printed from 65lb cardstock for extra durability.
