Owners Manual

For models: 43-205, 43-211, 43-213, 43-305, 43-350, & 43-351

Description: This manual covers the later version of the  Rockwell Heavy Duty Wood Shaper.  It is dated 1977.  It covers the Assembly, Belt Tension, Operating Controls, Spindle Changing, and it has a complete Parts Breakdown and List.  It also includes a bulletin on the 43-830 Fence Guard Assembly. It contains 20 pages. To inspect the quality of the manual, and to view select pages,  please click on the gallery images above to enlarge.  For the earlier version of this shaper see my Ebay Store.


Includes sections on:

• Nomenclature Chart
• Safety Rules
• Motor Installation
• Adjusting Belt Tension
• Fence Operating Controls
• Spindle Controls
• Changing Spindles
• Operation
• Shaping with Collars and Starting Pin
• Accessories
• Parts Breakdown
• Parts List
• 43-830 Fence Assembly Bulletin

Number of pages: Approx 20
Publication date:  July, 1977
Publication No.:  432-02-651-5001

Added Notes: Due to others making copies of these manuals for resale,
 I have lightly watermarked select pages to discourage this practice.

About This Manual:    This is a high quality reproduction manual which has been scanned with a high resolution scanner.  Each page is then digitally edited in Photoshop to remove grease marks, fingerprints, writing, and other imperfections that the original manual may have had.  It is then printed on 24 lb heavy paper and 65 lb cardstock for the covers with a 600 DPI LaserJet printer.  The result is a clean and durable manual which many times is better than the original and should last many years in your shop.

Questions?
Email: eugene@fabersurplus.com
Phone: 316-210-4079 after 11:00 am Central Time
Please leave message as I may not hear the phone

Ships USPS First Class Free or
Upgrade to Priority Mail for faster delivery.

Reprinted from original manual using high quality 24lb
paper and comb binding.

Covers are printed from 65lb cardstock for extra durability.

Sales tax charged for Kansas sales.
