Turchan Hydraulic Duplicator
Double Compound Attachment

 Operation and Service Manual

For models: Turchan Double Compound Attachment
Description: This is an Operation and Service manual for the Turchan Hydraulic Duplictor Double Compound Attachment.  It has sections on: General Construction, Operation of Complete Circuit, Method of Turning with Dual Turn, Hydraulic Power Unit, Setting Pressures, Oil Specifications, Power Feed, Tracer Valve, Feed Adjustment, Setting Up, & Tracer Tips.  It has 21 pages.  To inspect the quality of the manual, and to view select pages,  please click on the gallery images above to enlarge.


Includes sections on:

• General Construction

• Operation of Complete Circuit
• Method of Turning with Dual Turn
• Hydraulic Power Unit
• Setting Pressures
• Oil Specifications
• Power Feed
• Tracer Valve
• Feed Adjustment
• Setting Up
• Tracer Tips


Number of pages: Approx 21
Condition of original:   Good
Publication date: Appears to be from the 1940's
Publication No.:  N/A
Added Notes: Due to others making copies of these manuals for resale, I have lightly watermarked select pages to discourage this practice.

About This Manual:    This is a high quality reproduction manual which has been scanned with a high resolution scanner.  Each page is then digitally edited in Photoshop to remove grease marks, fingerprints, writing, and other imperfections that the original manual may have had.  It is then printed on 24 lb heavy paper and 65 lb cardstock for the covers with a 600 DPI LaserJet printer.  The result is a clean and durable manual which many times is better than the original and should last many years in your shop.
