Western Heavy Duty, Manufacturing, & Leader Type Radial Drills

Operating Instructions and Parts List

For models: Heavy Duty, Manufacturing, & Leader Type

Note:  This is a NOS manual in 6" x 8-3/4" format.

Description: This is a New Old Stock Operating Instructions & Parts List Manual for the Western Heavy Duty, Manufacturing, & Leader Type Radial Drills.  It has instructions on operation, lubrication, and a parts list with cutaway views.  The manual has 24 pages.  To inspect the quality of the manual, and to view select pages,  please click on the gallery images above to enlarge.

Includes sections on:

• Moving the Machine
• Foundation
• Cleaning

• Lubrication
• Operation

• Speed Selection
• Feed Selection
• Repair Parts List

Number of pages: Approx 24
Condition: Very Good
Publication date: N/A
Publication No.:  N/A
Added Notes: This is an original manual unused.  May show signs of rust on staples, and some discoloration
                             in some spots due to being exposed to the light. Otherwise these manuals are in excellent
                             condition.

About This Manual:    This is an original vintage manual.
