Western Machine Steptoe Shaper

Operating Instructions and Parts List

For models: ALL

Note:  This is a NOS manual in 6" x 8-3/4" format.

Description: This is a New Old Stock Operating Instructions & Parts List Manual for the Western Machine Steptoe Shaper. It has instructions on operation, adjustments,  Lubrication, and a parts list with cutaway views.  The manual has 16 pages.  To inspect the quality of the manual, and to view select pages,  please click on the gallery images above to enlarge.

Includes sections on:

• Moving the Machine
• Foundation
• Cleaning
• Automatic Forced Feed Lubrication
• Plain Lubrication
• Ram Stroke Adjustment
• Tool Slide Adjustment
• Feed Adjustment
• Speed Changing
• Vise Adjustment
• Power Down Feed
• Universal Table
• Tilting Table Top
• Power Rapid Traverse
• Motor Drive
• Repair Parts List

Number of pages: Approx 16
Condition: Very Good
Publication date: N/A
Publication No.:  N/A
Added Notes: This is an original manual unused.  May show signs of rust on staples, and some discoloration
                             in some spots due to being exposed to the light. Otherwise these manuals are in excellent
                             condition.

About This Manual:    This is an original vintage manual.
