For models: TE & TF

Description:  This is an Instruction Book for the Repair and Overhaul of the Wisconsin TE & TF  Single Cylinder Engines.  It contains all of the information necessary to repair or overhaul the Wisconsin Engine. It contains sections on Adjustments, Disassembly and Reassembly, Governors, Carburetors, Clutches, Lubrication, Magnetos and Repair, Timing, Troubleshooting, Valve Grinding, Etc.  It also contains the Exploded Parts Views and Parts Lists of the Engine, Clutch, Reduction Gears, Generator-Starter, Fuel Pump, Flywheel Magneto, & Carburetors.  It contains 74 Pages. To inspect the quality of the manual, to view the Table of Contents, and to view select pages, click on the above gallery pictures to enlarge.

Includes sections on:

• Disassembly & Reassembly of engine
• Carburetor service instructions
• Magneto service instructions
• Wiring diagrams
• Starting and operating instructions
• Governor adjustment
• Timing instructions
• Valve adjustments
• Troubleshooting
• Piston and crankshaft specifications
• Torque specifications
• Clutch reduction unit
• Exploded Parts Views
• Parts List

Number of pages: Approx 74
Publication No.:  MM-249-B
Publication date: N/A

About This Manual:    This is a high quality reproduction manual which has been scanned with a high resolution scanner.  Each page is then digitally edited in Photoshop to remove grease marks, fingerprints, writing, and other imperfections that the original manual may have had.  It is then printed on 24 lb heavy paper and 65 lb cardstock for the covers with a 600 DPI LaserJet printer.  The result is a clean and durable manual which many times is better than the original and should last many years in your shop.

Added Notes: Due to others making copies of these manuals for resale, I have lightly watermarked select pages to discourage this practice.

Questions?
Email: eugene@fabersurplus.com
Phone: 316-210-4079 after 11:00 am Central Time

Ships USPS First Class Free or
Upgrade to Priority Mail for faster delivery.
