Clausing 12" Lathe 5900 Series

Operating Instruction & Parts Manual

For models:12" 5900 series S/N's 501598 to 502099

Description: This is an Operation & Parts List Manual for the 12" Series 5900  Clausing Lathe. It has instructions on Operation,   Maintenance, Lubrication, Drive belts, Timing Belt, Adjustments, & Complete Parts Breakdown.  The manual has 55 pages.  To inspect the quality of the manual, to view the table of contents, and to view select pages,  please click on the gallery images above to enlarge.

Includes sections on:

• Installation
• Operating Instructions
• Control Operation
• Lubrication

• Feed Chart
• Service and Belt Adjustments
• Clutch Adjustment
• Gibs
• Countershaft Pulley Adjustment
• Spindle Bearings
• Upper Variable Control Cylinder
• Lower Variable Control Cylinder
• Shear Pin

• Assembly Breakdown Drawings
• Parts List


Number of pages: Approx 55

Publication date: December 1963
Publication No.:  5900-3
Added Notes:

About This Manual:    This is a high quality reproduction manual which has been scanned with a high resolution scanner.  Each page is then digitally edited in Photoshop to remove grease marks, fingerprints, writing, and other imperfections that the original manual may have had.  It is then printed on 24 lb heavy paper and 65 lb cardstock for the covers with a 600 DPI LaserJet printer.  The result is a clean and durable manual which many times is better than the original and should last many years in your shop.
