Clausing 14" Lathe 1500 Series

  Operating Instruction & Parts Manual

For models: 14" Series 1500

Note: For S/N's 151110 to 152258

Description: This is an Instruction & Parts List Manual for the 14" Series 1500 Clausing Lathe. It has instructions on Operation, Installation, Lubrication, Controls, Mantenance, Adjustments, and a  complete parts breakdown.  The manual has 37 pages.  To inspect the quality of the manual, to view the table of contents, and to view select pages,  please click on the gallery images above to enlarge.
Includes sections on:

• Operating Instructions
• Control Operation
• Lubrication
• Lubrication diagrams

• Clutch Adjustments
• Service and Belt Adjustments
• Gib Adjustments
• Belt Repacement
• Timing and Variable Speed Adjustments

• Assembly Breakdown Drawings
• Parts List


Number of pages: Approx 37

Publication date: March 1974
Publication No.:  1500-4
Added Notes:

About This Manual:    This is a high quality reproduction manual which has been scanned with a high resolution scanner.  Each page is then digitally edited in Photoshop to remove grease marks, fingerprints, writing, and other imperfections that the original manual may have had.  It is then printed on 24 lb heavy paper and 65 lb cardstock for the covers with a 600 DPI LaserJet printer.  The result is a clean and durable manual which many times is better than the original and should last many years in your shop.
