Clausing 14" Series 1500 Lathe

For models: 14" Series 1500

Note: For S/N's 150200-150418

Description: This is an Instruction & Parts List Manual for the 14" Series 1500 Clausing Lathe. It has instructions on Operation, Installation, Lubrication, Controls, Maintenance, Adjustments, and a  complete parts breakdown.  The manual has 48 pages and includes foldout pages on the Headstock and Drive Assemblies.  To inspect the quality of the manual, to view the table of contents, and to view select pages,  please click on the gallery images above to enlarge.

Includes sections on:

• Installation

• Lubrication

• Controls  and Operation

• Maintenance

• Adjustments


• Parts List


• Exploded Parts Breakdown


Number of pages: Approx 48

Publication date: July 1972

Publication No.:  N/A

About This Manual:    This is a high quality reproduction manual which has been scanned with a high resolution scanner.  Each page is then digitally edited in Photoshop to remove grease marks, fingerprints, writing, and other imperfections that the original manual may have had.  It is then printed on 24 lb heavy paper and 65 lb cardstock for the covers with a 600 DPI LaserJet printer.  The result is a clean and durable manual which many times is better than the original and should last many years in your shop.

Added Notes: Due to competitors making copies of these manuals for resale, select pages have been lightly watermarked to discourage this practice.
