Clausing Vertical Milling Machines 8520 & 8525
Instructions and Parts Manual

For models: 8520 & 8525

Description: This manual covers the Clausing Vertical Milling Machines 8520 & 8525.  It covers the Installation, Control Operations, Spindle Speeds, and has an complete parts breakdown and parts list.  It has 8 pages.   To inspect the quality of the manual, and to view select pages,  please click on the gallery images above to enlarge.


Includes sections on:

• Installation Instructions
• Motor wiring
• Control Operation
• Lubrication
• Spindle Speeds
• Mounting Cutters
• Parts Assembly Views
• Parts List

Number of pages: Approx 8
Publication date: November, 1966
Publication No.: 8520-9

Added Notes: Due to others making copies of these manuals for resale,
 I have lightly watermarked select pages to discourage this practice.

About This Manual:    This is a high quality reproduction manual which has been scanned with a high resolution scanner.  Each page is then digitally edited in Photoshop to remove grease marks, fingerprints, writing, and other imperfections that the original manual may have had.  It is then printed on 24 lb heavy paper and 65 lb cardstock for the covers with a 600 DPI LaserJet printer.  The result is a clean and durable manual which many times is better than the original and should last many years in your shop.
