Clausing Horizontal Milling Machines
Operating Instructions & Parts List

For models: 8540, 8541, 8550, & 8551

Covering Serial Numbers: 800817 and up.

Description: This is an Operation and Parts list manual for the Clausing Horizontal Milling Machines Models 8540, 8541, 8550, & 8551.  It covers the Installation, Lubrication, Operation, Maintenance and Adjustments, and a complete Parts Breakdown with Parts List.  It has 31 pages.    To inspect the quality of the manual, to view the Table of Contents, and to view select pages,  please click on the gallery images above to enlarge.


Includes sections on:

• Installation
• Lubrication
• Operation
• Drive Controls
• Spindle Speeds
• Motor Control
• Table, Saddle, and Knee Controls
• Power Longitudinal Feed Models
• Mounting Cutter Arbor
• Maintenance and Adjustments
• Preventative Maintenance
• Adjusting Gib
• Tensioning Power Feed Belts
• Tensioning Spindle Belts
• Adjusting Variable Belts
• Replacing Variable Belts
• Replacing Power Feed Belts
• Lower Variable Control Cylinder
• Upper Variable Control Cylinder
• Exploded Parts Views
• Parts List

Number of pages: Approx 31
Publication date: April, 1967
Publication No.: 8540-4

Added Notes: Due to others making copies of these manuals for resale,
 I have lightly watermarked select pages to discourage this practice.

About This Manual:    This is a high quality reproduction manual which has been scanned with a high resolution scanner.  Each page is then digitally edited in Photoshop to remove grease marks, fingerprints, writing, and other imperfections that the original manual may have had.  It is then printed on 24 lb heavy paper and 65 lb cardstock for the covers with a 600 DPI LaserJet printer.  The result is a clean and durable manual which many times is better than the original and should last many years in your shop.
