Clausing Colchester 21" Geared Head Engine Lathe

For models: 21"

Note: Starting at S/N: 06025 & up

Description: This is an Instruction & Parts List Manual for the 21" Clausing Colchester Lathe  beginning with serial number 06025 and up.   It has instructions on  Operation, Controls, Installation, Lubrication,  Adjustments, Alignment,  Wiring Diagram, complete Exploded Parts Views including the Parts List, Rapid Threader, Taper Turner, & Tool Posts.   The manual has 68 pages.  To inspect the quality of the manual, to view the Table of Contents, and to view select pages,  please click on the gallery images above to enlarge.

Includes sections on:

• Operation
• Controls

• Parts List

• Exploded Parts Views
• Machine Specifications

• Lubrication Chart
• Spindle Brake Adjustments

• Alignment Checks
• Installation
• Lubrication

• Wiring Diagram


Number of pages:Approx 68
Publication date: n/a
Publication No.:  n/a

About This Manual:    This is a high quality reproduction manual which has been scanned with a high resolution scanner.  Each page is then digitally edited in Photoshop to remove grease marks, fingerprints, writing, and other imperfections that the original manual may have had.  It is then printed on 24 lb heavy paper and 65 lb cardstock for the covers with a 600 DPI LaserJet printer.  The result is a clean and durable manual which many times is better than the original and should last many years in your shop.

Added Notes: Due to competitors making copies of these manuals for resale, select pages have been lightly watermarked to discourage this practice.
