Colchester Student 1800G Lathe

  Operating Instruction & Parts Manual

For models: Colchester 1800G

Covers Serial Numbers: 08818 up

Description: This is an Operation & Parts List Manual for the Colchester Student 1800G Lathe. It has instructions on Operation,   Maintenance, Lubrication, Drive belts, Timing Belt, Adjustments, & Complete Parts Breakdown.  The manual has 94 pages.  To inspect the quality of the manual, to view the table of contents, and to view select pages,  please click on the gallery images above to enlarge.
Includes sections on:

• Operating Instructions
• Control Operation
• Pre-Start Warning
• Electric Controls
• Lathe Controls
• Spindle Speeds
• Thread and Feed Selection
• Threading Dials
• Special Threads
• Apron Controls
• Versa Mil Mounting
• Lathe Alignment
• End Gear Train
• Drive Belts
• Shear Pin Protection
• Spindle Bearings
• Lubrication Diagrams
• Wiring Diagrams
• Assembly Breakdown Drawings
• Parts List


Number of pages: Approx 94

Publication date: N/A
Publication No.:  N/A
Added Notes:

About This Manual:    This is a high quality reproduction manual which has been scanned with a high resolution scanner.  Each page is then digitally edited in Photoshop to remove grease marks, fingerprints, writing, and other imperfections that the original manual may have had.  It is then printed on 24 lb heavy paper and 65 lb cardstock for the covers with a 600 DPI LaserJet printer.  The result is a clean and durable manual which many times is better than the original and should last many years in your shop.

Questions?
Email: eugene@fabersurplus.com
Phone: 316-210-4079 after 11:00 am Central Time

Ships USPS First Class Free or
Upgrade to Priority Mail for faster delivery.

Reprinted from original manual using high quality 24lb
paper and comb binding.

Covers are printed from 65lb cardstock for extra durability.

Sales tax charged for Kansas sales.
