Fairbanks Morse Magneto Instruction & Parts Manual

   FM-P  FM-PE & FM-PEF

For M274 Mule with Hercules Engine (and others)
Military Engine #2A042

Parts, Instruction, & Maintenance Manual

Description:   This is a high quality scanned reproduction of the original Fairbanks-Morsedealer servicing manual Instructions and latest Service Bulletins available.  Includes coil and condenser specifications, point settings, parts breakdown list, internal timing & general service information. It includes Bulleting FM-101C which is instructions on recharging the rotor magnets.
  Also included is a 16 page section on Magneto Service Practices by Fairbanks-Morse useful for bench servicing not only Fairbanks Morse, but magnetos of any brand.

For F-M Magneto models:     FM-P, FM-PE, and FM-PEF

Includes sections on:

• Field Service & Adjustment


• Parts List

• Specifications


• Assembly Drawings

• Recharging Magneto Rotor


• Magneto Service Practices

Number of pages: Approx 40

Publication No.:  3217

Publication date: April 1962

Includes:

•  Fairbanks Morse Instructions #3217

•  Bulletin FM30D

•  Bulletin FM101C


•  16 page section on Magneto Service Practices.

Questions?Email: eugene@fabersurplus.com

Phone: 316-210-4079 after 11:00 am Central Time

Ships USPS First Class Free or Upgrade to Priority Mail for faster delivery.
