 Rockwell 11" Metal Lathe Early Model

Instruction & Parts Manual

For models: Early Rockwell 11" S/N: 138-9100 & below

Description: This is a high quality reproduction manual  for the early production
Rockwell 11" lathes with    serial numbers 138-9100 and below.  It has sections on
Installation, Operation and Controls, Service adjustments, Belt Tension, Lubrication Chart,
Maintenance and Repairs, and a full parts diagrams and parts list. It also includes a 10 page
section on the electrical wiring diagrams not included in the original manual. This is the
latest revision to the early model 11" lathes put out by Rockwell. To inspect the
quality and to read the Table of Contents page, please click on the gallery images to enlarge.


Includes sections on:

• Installation
• Operation and Controls
• Service Adjustments
• Lubrication Chart
• Maintenance and Repairs
• Parts List
• Parts Breakdown Drawings
• 10 Page Wiring Diagram Section

Number of pages: Approx 55
Condition of original: Very Good
Publication No.:  414-01-651-5001
Publication date: 10-15-1964
Added Notes:  Due to others copying this manual for resale, I have added a light
watermark on select pages to discourage this practice.

Questions?
Email: eugene@fabersurplus.com
Phone: 316-210-4079 after 11:00 am Central Time

Ships USPS First Class Free or
Upgrade to Priority Mail for faster delivery.

Reprinted from original manual using high quality 24lb
paper and comb binding.

Covers are printed from 65lb cardstock for extra durability.
