Foley Belsaw M-14 Sawmill

Assembly, Operating Instructions, & Parts List Manual

For models: M-14

Description: This manual covers the Assembly, Operator Instructions & Parts List of the Foley Belsaw M-14 Sawmill.   It has sections on the Assembly Instructions for both the Wood Base and Steel Base, Operation, Troubleshooting, & Maintenance. It also has an exploded parts diagram and parts list.  It has 80 pages.  This is a nicely detailed all around Owners manual that is a must have for anyone that owns one of these gems.     To inspect the quality of the manual, to view the Table of Contents, and to view select pages,  please click on the gallery images above to enlarge.


Includes sections on:

• Assembly Instructions Steel Base
• Assembly Instructions Wood Base
• Building Concrete Footings for the Sawmill
• Leveling the Sawmill
• Final Mill Alignment
• Adjustments of Cable & Sheaves
• Board Splitter Adjustment
• Lead Adjustment
• Head Adjustments
• Direct Drive Shaft Assembly Instructions
• Off-Bearers Table Assembly Instructions
• Specifications
• How to Saw Logs
• Maintenance: Lubrication and Periodic
•  Sawblade Sharpening & Swaging
•  Sawteeth Removal & Installation
• Saw Tensioning & Hammering
• Troubleshooting
• Exploded Parts Diagram
• Parts List


Number of pages: Approx 80
Publication date: N/A
Publication No.: N/A

About This Manual:    This is a high quality reproduction manual which has been scanned with a high resolution scanner.  Each page is then digitally edited in Photoshop to remove grease marks, fingerprints, writing, and other imperfections that the original manual may have had.  It is then printed on 24 lb heavy paper and 65 lb cardstock for the covers with a 600 DPI LaserJet printer.  The result is a clean and durable manual which many times is better than the original and should last many years in your shop.

Added Notes: Due to others making copies of these manuals for resale,
 I have lightly watermarked select pages to discourage this practice.

Questions?
Email: eugene@fabersurplus.com
Phone: 316-210-4079 after 11:00 am Central Time

Ships USPS First Class Free or
Upgrade to Priority Mail for faster delivery.

Reprinted from original manual using high quality 24lb
paper and comb binding.

Covers are printed from 65lb cardstock for extra durability.

Sales tax charged for Kansas sales.
