Foley Belsaw Sawmill & Woodworking Machines
 Early Models

 Instructions and Parts List Manual

For models:Early Models

Description: This manual covers the early Belsaw Sawmill and accessories.  It shows how to build the sawmill base. It covers the Mandrel Assembly, Gummer  instructions, Carriage Units and operation, the Heavy Duty Power Feed, installing the drive belts, sheaves & cable, the Duo-Speed Power Feed, the Multi-Duty Planer and Accessories, Various Attachments, and Edger Instructions.    It has 14 pages.   To inspect the quality of the manual,  and to view select pages,  please click on the gallery images above to enlarge.


Includes sections on:

• Sawmill Base Construction
• Belsaw Mandrel Assembly
• Belsaw Gummer Instructions
• Sawmill Carriage Unit Parts Diagram & List
• Carriage Operation & Maintenance
• Belsaw Heavy Duty Power Feed
• Installing Drive Belt, Sheaves, & Cable
• Belsaw Feed for Light Sawmills
• Belsaw Multi-Duty Planer
• Belsaw Planer Accessories
• Muti-Duty Attachments
• Belsaw Edger Instructions


Number of pages: Approx 14
12Condition of original:   Very Good
Publication date: N/A
Publication No.: N/A
Added Notes: Due to others making copies of these manuals for resale, I have lightly watermarked select pages to discourage this practice.

About This Manual:    This is a high quality reproduction manual which has been scanned with a high resolution scanner.  Each page is then digitally edited in Photoshop to remove grease marks, fingerprints, writing, and other imperfections that the original manual may have had.  It is then printed on 24 lb heavy paper and 65 lb cardstock for the covers with a 600 DPI LaserJet printer.  The result is a clean and durable manual which many times is better than the original and should last many years in your shop.
