For models: CG-2 & CG-21

Description: This is an Operating Manual for the H.P. Preis Universal Cutter Grinder Models CG-2 & CG-21.    It contains Assembly Drawings, Operating Instructions, Mounting and Dressing of the Grinding Wheel, Grinding Side Cutting Edges on All Cutters, Grinding End Cutting Relief and End Cutting Rake, Grinding Round or Ball Nose Cutters, and Tables and Miscellaneous Instructions.   It  has 12 pages. To inspect the quality of the manual, and to view select pages,  please click on the gallery images above to enlarge.

Includes sections on:

• Assembly Drawings
• Operating Instructions
• Mounting & Dressing of the Grinding Wheel
• Grinding Side Cutting Edges on Cutters
• Grinding End Cutting Relief and End Cutting Rake
• Grinding Round or Ball Nose Cutters
• Tables and Miscellaneous Instructions


Number of pages: Approx 12
Publication date: N/A
Publication No.:  N/A

About This Manual:    This is a high quality reproduction manual which has been scanned with a high resolution scanner.  Each page is then digitally edited in Photoshop to remove grease marks, fingerprints, writing, and other imperfections that the original manual may have had.  It is then printed on 24 lb heavy paper and 65 lb cardstock for the covers with a 600 DPI LaserJet printer.  The result is a clean and durable manual which many times is better than the original and should last many years in your shop.

Added Notes:  Due to others making copies of these manuals for resale, I have lightly watermarked select pages to discourage this practice.

Questions?
Email: eugene@fabersurplus.com
Phone: 316-210-4079 after 11:00 am Central Time

Ships USPS First Class Free or
Upgrade to Priority Mail for faster delivery.
