Description: This is a 176 page training manual for Haas CNC Lathe SL Series. It was a manual that was used in classes offered by Haas. The first part covers: Display Modes, Operation Modes, Advanced Editor Features, Mem, MDI, DNC,  Please click on the above pictures to enlarge and view the table of contents and selected pages.

Note:  The second part of the manual beginning at page 71 is devoted to Advanced Lathe Programming.  There is no table of contents to this section but some of the sections are: Advanced Lathe Programming, Interpolation Commands, Linear/Circular Movement-Creating Tool Paths, Canned Cycles & Additional G-Codes

• Display Modes
• Operation Modes
• Advanced Editor Features
• Advanced Lathe Programming
• Interpolation Commands-Circular & Linear
• Manually Programming Tool Nose Compensation
• Tool Nose Radius Calculation
• Tool Nose and Angle Charts
• Miscellaneous G Codes
• Canned Cycles and Additional G-codes
• Machining Cycles for the Lathe

Publication Date: April 2008
Publication No.: N/A
Number of pages: Approx. 176

This manual is in very good condition.
It was obtained from an equipment dealer.
No grease smudges or fingerprints.
Appears to be new.
