Haas  CNC Lathe SL Series Operator and Programming
 Training Manual

Description: This is a 141 page training manual for Haas CNC Lathe SL Series Vertical Turning Center.  It was used in classes offered by Haas Factory Outlet.  Please click on the above pictures to enlarge and view the table of contents and selected pages. This manual was printed in August of 2013.


Incudes sections on:

• Introduction

• The Coordinate System
• Machine Home

• Absolute and Incremental Positioning
• Programming
• Alphabetical Address Codes
• Preparatory Functions (G Codes)
• Miscellaneous Functions (M Codes)
• Lathe Programming
• Machining Cycles For The Lathe
• Linear/Circular Movement-Creating Tool Paths
• Interpolation Commands
• Manually Programming Tool Nose Compensation
• Tool Nose Radius Calculation Diagram
• Miscellaneous G Codes
• Work Coordinate System Selection
• Tool Nose Compensation Programming
• Canned Cycles And Additional G Codes
• Tool Nose Compensation In Canned Cycles
• Type I Details
• Type II Details
• Drilling, Boring, and Tapping Canned Cycles
• M Code Detailed Description


Publication Date: August 2013
Publication No.: N/A
Number of pages: Approx. 141

This manual is in very good condition.
It was obtained from an equipment dealer.
No grease smudges or fingerprints.
Appears to be new.


Questions?
Email: eugene@fabersurplus.com
Phone: 316-210-4079 after 11:00 am Central Time
Please leave message if no answer.

Ships USPS Priority Free
International Customers please contact me first.
