Hendey  12 and 18 Speed Geared Head Lathe

  Operating & Parts Manual

For models: 12 and 18 Speed Lathes

Description: This manual covers the parts list and assembly breakdown of the Hendey Lathe. It also has a section on thread cutting with two index tables included. It has the formulas for figuring gears for threads not given in the tables. The original had some pictures that were somewhat faint, which can be seen in the included pictures.   To inspect the quality, please click on the gallery images above to enlarge.

Includes sections on:

• Cutting Scrolls with Apron Cross Feed
• Thread Cutting Gear Formulas
• Thread Cutting Charts

• Parts List
• Parts Breakdown


Number of pages: Approx 14
Condition of original: Good, with parts pictures somewhat faint
Publication No.:  N/A
Publication date: N/A
Added Notes:

About This Manual:  This is a high quality reproduction manual which has been scanned with a high resolution scanner.  Each page is then digitally edited in Photoshop to remove grease marks, fingerprints, writing, and other imperfections that the original manual may have had.  It is then printed on 24 lb heavy paper and 65 lb cardstock for the covers with a 600 DPI LaserJet printer.  The result is a clean and durable manual which many times is better than the original and should last many years in your shop.

Questions?
Email: eugene@fabersurplus.com
Phone: 316-210-4079 after 11:00 am Central Time

Ships USPS First Class Free or
Upgrade to Priority Mail for faster delivery.

Reprinted from original manual using high quality 24lb
paper and comb binding.

Covers are printed from 65lb cardstock for extra durability.

Sales tax charged for Kansas sales.

<
