Landis 10" & 14" Type IWR Semi-Automatic Hydraulic Multiple Wheel Grinding Machine

Installation, Operation, & Maintenance Manual

For models: 10" & 14" Type IWR


Description: This is an Installation, Operation, & Maintenance  Manual for the 10" & 14" Type IWR Semi- Automatic Grinder. It has sections on Operation, Installation,  Lubrication, Hydraulic System, Maintenance, and more.  The manual has 20 pages.  To inspect the quality of the manual, to view the table of contents, and to view select pages,  please click on the gallery images above to enlarge.

Includes sections on:

• Operating Controls
• Installation Instructions
• Headstock
• Footstock
• Work Carriage
• Multiple Wheel Assembly
• Adjusting the Bearing Clearance
• Hydraulic System
• Lubrication
• Grinding Wheel Feed
• Side Dressing the Grinding Wheels
• Face Dressing the Grinding Wheels
• Adjusting the Work Rests
• The Grinding Cycle
• Preventive Maintenance


Number of pages: Approx 20
Condition: Very Good
Publication date: N/A
Publication No.:  N/A
Added Notes: Due to others making copies of these manuals for resale, select
                            pages have been lightly watermarked to discourage this practice.

About This Manual:    This is a high quality reproduction manual which has been scanned with a high resolution scanner.  Each page is then digitally edited in Photoshop to remove grease marks, fingerprints, writing, and other imperfections that the original manual may have had.  It is then printed on 24 lb heavy paper and 65 lb cardstock for the covers with a 600 DPI LaserJet printer.  The result is a clean and durable manual which many times is better than the original and should last many years in your shop.
