Merc-O-Tronic Ignition Analyzer Model 88
  Operation and Data Manual

For models: 88

Description:  This is the latest 1978 revision of  an Operation and Test Data Manual for the Merc-O-Tronic  Model 88 Ignition Analyzer.  These analyzers were produced up through the 1960's and were widely used for testing ignition coils, condensers, diodes, armatures, field windings, selenium rectifiers, timing, etc. on Magnetos, Lawn Mowers, Tractors, Automotive, Marine Engines, Snowmobiles, Motorcycles, etc. The manual is reproduced in color same as the original.  It is 148 pages long, including the latest specifications on equipment that is not included in the earlier versions being offered elsewhere.  Please enlarge the gallery images above to view the Table of Contents, select pages, and to view the quality of the manual.

Includes sections on:

• Operation
• Armature Ground Test
• Automotive Type Coils
• Breaker Point Test Coil Continuity Test
• Coil Ground Test
• Coil Power Test
• Coil High Speed Test
• Coil Surface Insulation Test
• Condenser Test
• Continuity Test
• Service Notes and Operation Instructions
• Distribution Rotor Test
• Field Winding Ground Test
• High Tension Leakage-Crack Test (Distributor)
• Resistance Test (Low OHMS and Coil Primary)
• Spark Test (Ignition)
• Starter Soleniod Test
• Testing Coil with Two Secondaries
• Testing Conventional Type Magnetos
• Testing Diodes
• Testing Selenium Rectifiers
• Timing (Static)
• Coil and Condenser specifications (104 pages)

Number of pages: Approx 148
Condition of original: Very  Good
Publication No.:N/A
Publication/Revision Date: 1978
