Rockwell 14" Lathe Operation, Service, & Parts List Manual Early Version *1271
Price:
$35.00
SKU:
1271
Brand:
Availability:
Ships within one business day
Shipping:
Free Shipping
Product Description
Rockwell 14" Lathe
Earlier version w/ handwheel variable speed control
Operation, Service, & Repair Parts List Manual
Description: This is an Operation, Service, and Repair Manual for the Rockwell 14" Lathe early version. The early version has a handwheel for the variable speed control and no Spindle Brake Lever on top. It contains instructions on the Installation, Operation, Controls, Adjustments, Lubrication, Maintenance, and Repairs, and Exploded Parts Views with Parts List. The manual has 64 pages. To inspect the quality of the manual, to view the Table of Contents and to view select pages, please click on the gallery images above to enlarge.
Includes sections on:
- Installation
- Operation
- Lubrication
- Lubrication Chart
- Controls
- Quick Change Gear Box
- Carriage
- Tailstock
- Variable Speed Drive
- Service Adjustments
- Replacing Shear Pins
- Belt Adjustments
- Clutch Adjustments
- Maintenance & Repairs Including:
- Headstock
- Belt Drive System
- Quick Change Gear Box
- Apron
- Exploded Parts Views
- Parts List
Number of pages: Approx 64
Publication date: Feb 1966
Publication No.: PM-414-03-651-5002
About This Manual: This is a high quality reproduction manual which has been scanned with a high resolution scanner. Each page is then digitally edited in Photoshop to remove grease marks, fingerprints, writing, and other imperfections that the original manual may have had. It is then printed on 24 lb heavy paper and 65 lb cardstock for the covers with a 600 DPI LaserJet printer. The result is a clean and durable manual which many times is better than the original and should last many years in your shop.
Added Notes: Due to competitors making copies of these manuals for resale, select pages have been lightly watermarked to discourage this practice.
