For models: 17"  Beginning with s/n: 137-5800 up.

Description: This is an Operation and  Parts List manual for the Rockwell / Delta 17" Variable Speed Drill Press.  It has sections on:  Operation,  Adjustments, Maintenance, Repairs, Exploded Parts Diagrams, & Parts List.  It has 20 pages. and was printed in 1965.  To inspect the quality of the manual,  to view the Table of Contents, and to view select pages,  please click on the gallery images above to enlarge.


Includes sections on:

• Operation


• Adjustments

• Repairs

• Setting Up

• Variable Speed Control

• Motors & Speeds

• Replacing Shear Pin

• Changing Lower Spindle Assembly

• Quill Adjustments

• Adjusting Spindle Return Spring

• Adjusting Belt Tension

• R & R Upper Spindle, Spindle Pulley & Related Parts

• Parts List


• Exploded View Drawings


Number of pages: Approx 20
Condition of original:   Very Good
Publication date: March 1965
Publication No.: PM-402-07-651-5007

About This Manual:    This is a high quality reproduction manual which has been scanned with a high resolution scanner.  Each page is then digitally edited in Photoshop to remove grease marks, fingerprints, writing, and other imperfections that the original manual may have had.  It is then printed on 24 lb heavy paper and 65 lb cardstock for the covers with a 600 DPI LaserJet printer.  The result is a clean and durable manual which many times is better than the original and should last many years in your shop.

Added Notes: Due to others making copies of these manuals for resale, I have lightly watermarked select pages to discourage this practice.

Questions?
Email: eugene@fabersurplus.com
Phone: 316-210-4079 after 11:00 am Central Time

Ships USPS First Class Free or
Upgrade to Priority Mail for faster delivery.

Reprinted from original manual using high quality 24lb
paper and comb binding.

Covers are printed from 65lb cardstock for extra durability.

Sales tax charged for Kansas sales.
