 Rockwell Delta 20" Series 2000 Variable Speed Drill Press

For models: All 20" Series 2000 Variable Speed Model Numbers:70-6X0, 70-300 to 70-368, 70-370 to 70-398, 70-610 to 70-636

Description: This is a Operators and  Parts List manual for the Rockwell 20" Series 2000 Variable Speed Drill Press. It has sections on: Operation, Adjustments, Maintenance, Exploded Parts Diagrams, & Parts List.   It has 44 pages.  There were two versions of this variable speed drill press, and both manuals are included together so as to cover all models. This manual does not cover the step pulley models, which is a separate manual sold in my Ebay store.  Also included is supplements which cover the 20-600 variable rate power feed, the 20-629 mechanical power feed, the 402-07-367-5003 mechanical power feed retrofit kit, and the table and head raising mechanisms. To inspect the quality of the manual,  and to view select pages,  please click on the gallery images above to enlarge.


Includes sections on:

• Operation
• Variable Speed Control
• Quill Adjustments
• Changing Spindles
• Changing Belts
• Variable Rate Power Feed Supplement

• Mechanical Power Feed Supplement
• Mechanical Power Feed Retrofit Supplement
• Table & Head Raising Mechanism Supplement

• Exploded Parts Views
• Parts Lists

Number of pages: Approx 44
Publication date: Jan-Feb 1972
Publication No.: P-1200328, PM-1200883 plus supplements

Added Notes:  Due to others making copies of these manuals for resale,
                      I have lightly watermarked select pages to discourage this practice.

About This Manual:    This is a high quality reproduction manual which has been scanned with a high resolution scanner.  Each page is then digitally edited in Photoshop to remove grease marks, fingerprints, writing, and other imperfections that the original manual may have had.  It is then printed on 24 lb heavy paper and 65 lb cardstock for the covers with a 600 DPI LaserJet printer.  The result is a clean and durable manual which many times is better than the original and should last many years in your shop.

Questions?
Email: eugene@fabersurplus.com
Phone: 316-210-4079 after 11:00 am Central Time

Ships USPS First Class Free or
Upgrade to Priority Mail for faster delivery.

Reprinted from original manual using high quality 24lb
paper and comb binding.

Covers are printed from 65lb cardstock for extra durability.

Sales tax charged for Kansas sales.
