For models: Sheldon No.'s R13, R15, R17

Description: This is an Instruction Manual for the Sheldon No.'s R13, R15, & R17 Precision Lathes. It has sections on Lathe Installation, Lubrication, Operation, Adjustments, Belts, Troubleshooting List, and Wiring Diagrams. It has 24 pages.  To inspect the quality of the manual, and to view select pages,  please click on the gallery images above to enlarge.

Includes sections on:

• Lathe Installation
• Operating Procedures
• Lubrication
• Selection of Threads & Feeds
• Apron & Carriage
• Sheldon Cross Slide
• Telescopic Taper Attachment
• Adjusting the Headstock Spindle Bearings
• Motor Drive Belts
• Lead Screw and Feed Rod End Play
• Dissassembly of Lead Screw and Feed Rod
• Compound and Cross Slide Gibs
• Wiring Diagrams
• Electrical Troubleshooting (General)


Number of pages: Approx 24
Publication date: N/A
Publication No.:  N/A

About This Manual:    This is a high quality reproduction manual which has been scanned with a high resolution scanner.  Each page is then digitally edited in Photoshop to remove grease marks, fingerprints, writing, and other imperfections that the original manual may have had.  It is then printed on 24 lb heavy paper and 65 lb cardstock for the covers with a 600 DPI LaserJet printer.  The result is a clean and durable manual which many times is better than the original and should last many years in your shop.

Added Notes:   Due to others making copies of these manuals for resale, I have lightly watermarked select pages to discourage this practice.

Questions?
Email: eugene@fabersurplus.com
Phone: 316-210-4079 after 11:00 am Central Time

Ships USPS First Class Free or
Upgrade to Priority Mail for faster delivery.

Reprinted from original manual using high quality 24lb
paper and comb binding.

Covers are printed from 65lb cardstock for extra durability.

Sales tax charged for Kansas sales.
