Sheldon R13, R15, & R17 Precision Lathes

 Parts List  Manual

For models: Sheldon No.'s R13, R15, R17

Description: This is a Parts List Manual for the Sheldon No.'s R13,R15, & R17 Precision Lathes. It has a  complete parts list with a parts assembly breakdown. It has 27 pages.  To inspect the quality of the manual, and to view select pages,  please click on the gallery images above to enlarge.


Includes sections on:

• Assembly Breakdown Drawings
• Parts List

Number of pages: Approx 27
Condition of original:   Very Good
Publication date: N/A
Publication No.:  N/A

Added Notes:   Due to others making copies of these manuals for resale, I have lightly watermarked select pages to discourage this practice.

About This Manual:    This is a high quality reproduction manual which has been scanned with a high resolution scanner.  Each page is then digitally edited in Photoshop to remove grease marks, fingerprints, writing, and other imperfections that the original manual may have had.  It is then printed on 24 lb heavy paper and 65 lb cardstock for the covers with a 600 DPI LaserJet printer.  The result is a clean and durable manual which many times is better than the original and should last many years in your shop.
