For models: Series I Late Model w/Powerfeed

Description: This is the latest manual dated 1993 for the Series I that Bridgeport put out.  While most of the parts and operation is the same as what is covered in the earlier manuals, what sets this manual apart is the inclusion of the powerfeed features and also the wiring diagrams of not only the powerfeed, but of the complete mill. It also includes any changes made in the later years. This is a fairly large manual at 127 pages.  To view the Table of Contents, to inspect the quality of the printing, and to view select pages, please click on the above gallery thumbnails.

Includes sections on:

• Specifications
• Speed Recommendations
• 2J Head
• J Head
• E-Head (shaper)
• Electrical Diagrams
• Installation
• Lubrication
• Operation
• Power Feed Control
• E-Head Control (Shaper Head)
• Head Maintenance
• Gib Adjustments
• Backlash Adjustments
• E-Head Maintenance
• Parts
• Replacement Assemblies, Spart Parts
• Metric Conversion Kits


Number of pages: Approx 127
Publication No.:  1104001
Publication date: April 1993
Added Notes:

About This Manual:  This is a high quality reproduction manual which has been scanned with a high resolution scanner.  Each page is then digitally edited in Photoshop to remove grease marks, fingerprints, writing, and other imperfections that the original manual may have had.  It is then printed on 24 lb heavy paper and 65 lb cardstock for the covers with a 600 DPI LaserJet printer.  The result is a clean and durable manual which many times is better than the original and should last many years in your shop.
