Case 4-JMA & 4-CMA Magneto Manual

Description:   This is a  Dealers Service Manual that covers the Case 4-JMA & 4-CMA Magnetos. It includes instructions on the disassembly and reassembly of the magneto, equipment required for service, Running Tests, Timing, Field Servicing, exploded parts views with part numbers, and much other information useful for servicing these mags.  Also included is point settings and gear timing.  It has 50 pages of very useful service information.  To inspect the quality of the manual, to view the Table of Contents, and to view select pages, please click on the above gallery images to enlarge.

For Case Magneto models:   4-JMA & 4-CMA

Includes sections on:

• Equipment Required
• Running Tests
• Timing
• Field Servicing
• Disassembly
• Reassembly
• Point Settings

• Exploded Parts Views
• Part Numbers


Number of pages: Approx 50
Publication No.:  N/A
Publication date: N/A

About This Manual:    This is a high quality reproduction manual which has been scanned with a high resolution scanner.  Each page is then digitally edited in Photoshop to remove grease marks, fingerprints, writing, and other imperfections that the original manual may have had.  It is then printed on 24 lb heavy paper and 65 lb cardstock for the covers with a 600 DPI LaserJet printer.  The result is a clean and durable manual which many times is better than the original and should last many years in your shop.

Added Notes: Due to others making copies of this manual for resale,I have placed a light watermark on select pages to discourage this practice.

Questions?
Email: eugene@fabersurplus.com
Phone: 316-210-4079 after 11:00 am Central Time

Ships USPS First Class Free or
Upgrade to Priority Mail for faster delivery.
