Clausing 10" Lathe 4900 Series

Operating Instruction & Parts Manual

For models: 10" 4900 Series
For Serial Numbers: 401710 to 403160

Description:  This is an Operation & Parts List Manual for the 10" Series 4900  Clausing Lathe. It has instructions on  Operation, Lubrication,  Maintenance, Drive belts, & Adjustments & Complete Parts Breakdown.  The manual has 35 pages.  To inspect the quality of the manual, to view the table of contents, and to view select pages,  please click on the gallery images above to enlarge.

Includes sections on:

• Operating Instructions
• Control Operation
• Back Gear Controls
• Quick Change Gear Box
• Tool Holders
• Chucks and Face Plates

• Lubrication

• Lubrication Chart
• Preventative Maintenance
• Carriage Bearing Plates
• Shear Pin
• Spindle Bearing

• Service and Belt Adjustments
• Gibs

• Assembly Breakdown Drawings
• Parts List


Number of pages: Approx 35

Publication date: March, 1967
Publication No.:  4910-2
