Clausing 14" Lathe 6900 Series

  Operating Instruction & Parts Manual

For models: 14"  6900 Series

For Serial Numbers: 602504 and up

Description:
This is an Operating Instruction & Parts List Manual for the 14" Series 6900  Clausing Lathe. It has instructions on  operation, complete parts breakdown,  Maintenance, Lubrication, Drive belts, Timing Belt, & Adjustments.  The manual has 42 pages.  To inspect the quality of the manual, to view the table of contents, and to view select pages,  please click on the gallery images above to enlarge.

Includes sections on:

• Installation

• Operating Instructions

• Control Operation
• Lubrication

• Feed Chart

• Service and Belt Adjustments
• Clutch Adjustment
• Gibs
• Countershaft Pulley Adjustment
• Spindle Bearings
• Upper Variable Control Cylinder
• Lower Variable Control Cylinder
• Shear Pin

• Assembly Breakdown Drawings
• Parts List

Number of pages: Approx 42

Publication date: March 1967
Publication No.:  6900-6
Added Notes:

About This Manual:    This is a high quality reproduction manual which has been scanned with a high resolution scanner.  Each page is then digitally edited in Photoshop to remove grease marks, fingerprints, writing, and other imperfections that the original manual may have had.  It is then printed on 24 lb heavy paper and 65 lb cardstock for the covers with a 600 DPI LaserJet printer.  The result is a clean and durable manual which many times is better than the original and should last many years in your shop.

Questions?
Email: eugene@fabersurplus.com
Phone: 316-210-4079 after 11:00 am Central Time

Ships USPS First Class Free or
Upgrade to Priority Mail for faster delivery.

Reprinted from original manual using high quality 24lb
paper and comb binding.

Covers are printed from 65lb cardstock for extra durability.

Sales tax charged for Kansas sales.
