Clausing 12" Models 3995, 3996 Lathe Op & Parts List sn's:100200 to 103991 #1470
Product Description
Clausing 12" Lathe Models 3995 & 3996
Operating Instruction & Parts Manual
For models: 12" 3995 & 3996
Covers Serial Numbers: 100200 to 103991
Description:This is an Operating Instruction and Parts List Manual for the Clausing 12" Lathe Models 3995 & 3996. It has instructions on how to level the lathe, control functions and operation, Maintenance, & Adjustments. It also has instructions for lubrication. It contains a complete parts list with assembly breakdown drawings. It is dated 1974 and has 28 pages. To inspect the quality of the manual, view the table of contents, and to view select pages, please click on the gallery images above to enlarge.
Includes sections on:
- Operating Instructions
- Control Operation
- Back Gear Controls
- Quick Change Gear Box
- Sequence of Engaging Controls
- Carriage
- Lubrication
- Preventative Maintenance
- Adjusting Gibs
- Adjusting Spindle Bearings
- Adjusting Compound & Cross Feed Cranks
- Adjusting Lead Screw Safety Clutch
- Assembly Breakdown Drawings
- Parts List
Number of pages: Approx 28
Publication date: December 1974
Publication No.: 12AC
Added Notes:About This Manual: This is a high quality reproduction manual which has been scanned with a high resolution scanner. Each page is then digitally edited in Photoshop to remove grease marks, fingerprints, writing, and other imperfections that the original manual may have had. It is then printed on 24 lb heavy paper and 65 lb cardstock for the covers with a 600 DPI LaserJet printer. The result is a clean and durable manual which many times is better than the original and should last many years in your shop.
