For models: 4800

Note: Starting at S/N: 16758 to 17434

Description: This is an Operation & Parts List Manual for the 12" Series 4800  Clausing Lathe  beginning with serial number 16758 to 17434. This manual will also work with lathes that have serial numbers lower, with the difference being in the tailstock.  It has instructions on  Operation,  Maintenance and Controls, Lubrication,  Adjustments, complete Exploded Parts Views, and a Numerical Parts List.   The manual has 30 pages.  To inspect the quality of the manual, to view the table of contents, and to view select pages,  please click on the gallery images above to enlarge.

Includes sections on:

• Operation
• Parts List

• Exploded Parts Views

• Controls
• Installation
• Maintenance
• Adjustments
• Lubrication

• Selection of Threads and Feeds
• Carriage Feed Chart
• Belt Adjustment
• Remove & Replace Headstock Spindle
• Remove & Replace Back-Gears
• Clutch Countershaft Adjustment


Number of pages: Approx 30
Publication date: July 1954
Publication No.:  4800-5

About This Manual:    This is a high quality reproduction manual which has been scanned with a high resolution scanner.  Each page is then digitally edited in Photoshop to remove grease marks, fingerprints, writing, and other imperfections that the original manual may have had.  It is then printed on 24 lb heavy paper and 65 lb cardstock for the covers with a 600 DPI LaserJet printer.  The result is a clean and durable manual which many times is better than the original and should last many years in your shop.

Added Notes: Due to competitors making copies of these manuals for resale, select pages have been lightly watermarked to discourage this practice.
