Clausing 15" Lathe 6500 Series
Geared Head

  Operating Instruction & Parts Manual

For models: 15" 6500 Series

For Serial Numbers:  1 through 42421

Description:
This is an Instruction & Parts List Manual for the 15" Series 6500  Clausing Lathe. It has instructions on  operation, complete parts breakdown,  Maintenance, Lubrication,  & Adjustments.  The manual has 34 pages.  To inspect the quality of the manual, to view the table of contents, and to view select pages,  please click on the gallery images above to enlarge.

Includes sections on:

• Headstock
• Installation

• Control Operation
• Carriage
• Apron
• Tailstock
• Coolant Unit

• Lubrication

• Wiring Diagram
• Service Hints
• Adjustments

• Part Removal and Replacement

• Pictorial Breakdown Drawings
• Parts List


Number of pages: Approx 34

Publication date: October 1963
Publication No.:  6530-2
