For models: 6"x 24" Student and 12"x 24" Dominion

Description: This is an Instruction and  Parts List Manual for the Cholchester Student and Dominion Lathes. It contains instructions on the Installation, Operation, Thread Cutting, Rapid Threading Unit, Telescopic Taper Turner, Series 300 Hydraulic Profiling Unit, Lubrication, Wiring Diagrams,  Parts Lists, and Exploded Parts Views.  The manual has 100 pages.  To inspect the quality of the manual,  and to view select pages,  please click on the gallery images above to enlarge.

Includes sections on:

• Installation

• Operation

• Lubrication

• Specifications

• Wiring Diagrams

• Alignment Checks

• Gearbox Charts

• Thread Cutting

• Thread Chart

• Metric Feeds and Threads

• Multi Start Threads

• English Threads

• Suds Unit

• Toolposts

• Rapid Threading Unit (Metric & Engish)

• Telescopic Taper Turner

• Series 300 Hydraulic Profiling Unit

• Third Shaft Control Unit


• Parts List


• Exploded Parts Views


Number of pages: Approx 100

Publication date: October 1967

Publication No.:  N/A

About This Manual:    This is a high quality reproduction manual which has been scanned with a high resolution scanner.  Each page is then digitally edited in Photoshop to remove grease marks, fingerprints, writing, and other imperfections that the original manual may have had.  It is then printed on 24 lb heavy paper and 65 lb cardstock for the covers with a 600 DPI LaserJet printer.  The result is a clean and durable manual which many times is better than the original and should last many years in your shop.

Added Notes:Due to competitors making copies of these manuals for resale, select pages have been lightly watermarked to discourage this practice.
