Delta Multiplex 20-A Radial Arm Saw


 Instruction and Parts List Manual

For models: Delta 20-A Multiplex

Description: This is an Instruction and Parts List manual for the Delta 20-A Multiplex Radial Arm Saw.  It has sections on: Operation, Maintenance, Assembly, Adjustments, Expanded Parts Diagrams, & Parts List. It has instructions on how to set up for multiple woodworking operations including Compound Mitering, Dadoing, Ploughing, Tenoning, Rabbeting, Grooving, Moulding, Routing, Shaping, Planing, Sanding, and others.  It has 24 pages. and was printed in 1950.  To inspect the quality of the manual,  and to view select pages,  please click on the gallery images above to enlarge.


Includes sections on:

• Operation
• Maintenance
• Assembly
• Adjustments

• Setup Instructions for numerous operations

• Parts List
• Expanded Parts Diagrams

• Rabbeting
• Moulding
• Routing
• Shaping

• Planing

• Compound Mitering


Number of pages: Approx 24
Condition of original:   Very Good
Publication date: 1950
Publication No.:  PM-1727
Added Notes: Due to others making copies of these manuals for resale, I have lightly watermarked select pages to discourage this practice.

About This Manual:    This is a high quality reproduction manual which has been scanned with a high resolution scanner.  Each page is then digitally edited in Photoshop to remove grease marks, fingerprints, writing, and other imperfections that the original manual may have had.  It is then printed on 24 lb heavy paper and 65 lb cardstock for the covers with a 600 DPI LaserJet printer.  The result is a clean and durable manual which many times is better than the original and should last many years in your shop.
