For models: 12" Beginning with s/n EX-700

Description: This is an Operation and  Parts List manual for the Rockwell / Delta 12" Radial Arm Saw.   It has sections on:  Operation,  Maintenance, Wiring Diagrams including Magnetic Control, Exploded Parts Diagrams, & Parts List.  It has 32 pages. and was printed in 1972.  To inspect the quality of the manual,  and to view select pages,  please click on the gallery images above to enlarge.

Includes sections on:

• Operation

• Assembly


• Adjustments
• Adjusting Table Top Parallel to Track Arm
• Adjusting Ball Bearings Against Track
• Adjusting Blade Square with Table Top
• Adjusting Saw Travel Square with Fence
• Removing "Heeling" in Saw Cut
• Wiring Diagrams
• Exploded View Drawings & Parts List

Number of pages: Approx 32
Publication date: Jun 15 1972
Publication No.: 424-02-651-0003

About This Manual:    This is a high quality reproduction manual which has been scanned with a high resolution scanner.  Each page is then digitally edited in Photoshop to remove grease marks, fingerprints, writing, and other imperfections that the original manual may have had.  It is then printed on 24 lb heavy paper and 65 lb cardstock for the covers with a 600 DPI LaserJet printer.  The result is a clean and durable manual which many times is better than the original and should last many years in your shop.

Added Notes: Due to others making copies of these manuals for resale, I have lightly watermarked select pages to discourage this practice.

Questions?
Email: eugene@fabersurplus.com
Phone: 316-210-4079 after 11:00 am Central Time

Ships USPS First Class Free or
Upgrade to Priority Mail for faster delivery.

Reprinted from original manual using high quality 24lb
paper and comb binding.

Covers are printed from 65lb cardstock for extra durability.

Sales tax charged for Kansas sales.
